M804010 Inch Tapered Roller Bearings
M804010 Inch Tapered Roller Bearings
M804010 Inch Tapered Roller Bearings
Diagram of DSBR Inch Tapered Roller Bearings
Diagram of DSBR Inch Tapered Roller Bearings

M804049/M804010 Inch Tapered Roller Bearings

The M804049/M804010 tapered roller bearing is designed for robust automotive and industrial applications. Its inch-series construction offers excellent compatibility and efficient load handling for radial and axial forces. Made from premium alloy steel, this bearing undergoes precise grinding and advanced heat treatment to ensure long service life and resistance to wear. Its separable design makes installation, inspection, and replacement easier. With DSBR’s stringent manufacturing control, this bearing delivers OEM-grade performance, making it an ideal choice for global distributors and aftermarket supply chains.

Contact Us download
Products
Technical Specification Technical Specification

Technical Specification of M804049/M804010 Inch Tapered Roller Bearings

Specifications
SeriesM804000
Cone Part NumberM804049
Cup Part NumberM804010
Design UnitInch
Cage MaterialStamped Steel
Related Assembly Number(s)M804049-90010
Dimensions
d - Bore1 7/8 in
47.625 mm
D - Cup Outer Diameter3 1/2 in
88.900 mm
B - Cone Width1.0000 in
25.400 mm
C - Cup Width0.7500 in
19.050 mm
T - Bearing Width1.0000 in
25.400 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius10.14 in
3.560 mm
r - Cup Backface "To Clear" Radius20.130 in
3.30 mm
da - Cone Frontface Backing Diameter2.2 in
56 mm
db - Cone Backface Backing Diameter2.56 in
65 mm
Da - Cup Frontface Backing Diameter3.39 in
85.10 mm
Db - Cup Backface Backing Diameter3.03 in
76.96 mm
Ab - Cage-Cone Frontface Clearance0.1 in
2.5 mm
Aa - Cage-Cone Backface Clearance0.05 in
1.3 mm
a - Effective Center Location3-0.07 in
-1.8 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)4

5740 lbf

25600 N

C1 - Dynamic Radial Rating (1 million revolutions)522200 lbf
98600 N
C0 - Static Radial Rating26100 lbf
116000 N
Ca90- Dynamic Thrust Rating (90 million revolutions)65370 lbf
23900 N
Factors
K - Factor71.07
e - ISO Factor80.55
Y - ISO Factor91.1
G1 - Heat Generation Factor (Roller-Raceway)33.9
G2 - Heat Generation Factor (Rib-Roller End)12.5
Cg - Geometry Factor100.0924
