33116 3007716E Metric Tapered Roller Bearings
33116 3007716E Metric Tapered Roller Bearings
33116 3007716E Metric Tapered Roller Bearings
diagram of dsbr metric tapered roller bearings
diagram of dsbr metric tapered roller bearings (2)

33116 3007716 Metric Tapered Roller Bearings

The 33116 3007716 tapered roller bearing by DSBR is designed to provide consistent performance under heavy radial and axial loads. It features premium-grade alloy steel, precision-ground rollers, and heat-treated races for superior wear resistance. Widely used in automotive gearboxes and mining machinery, the 33116 excels in demanding environments with minimal maintenance.

Ideal for heavy-duty applications, they offer:

  • Excellent capacity for both radial and axial forces

  • Support for axial loads in a single direction

  • Reduced friction for efficient, high-speed operation

  • Durable, replaceable, and service-friendly design


Contact Us download
Products
Technical Specification Technical Specification

Technical Specification of 33116 3007716 Metric Tapered Roller Bearings

dimensions of 30204 7204e metric tapered roller bearings

Dimensions
d80 mmBore diameter
D130 mmOutside diameter
B37 mmWidth of inner ring
C29 mmWidth of outer ring
T37 mmTotal width
r1,2min.2 mmChamfer dimension of inner ring
r3,4min.1.5 mmChamfer dimension of outer ring
a31 mmDistance side face to pressure point

d1≈106.6 mmShoulder diameter of inner ring


abutment dimensions of 30204 7204e metric tapered roller bearings

Abutment dimensions
damax.89 mmDiameter of shaft abutment
dbmin.89 mmDiameter of shaft abutment
Damin.114 mmDiameter of housing abutment
Damax.121 mmDiameter of housing abutment
Dbmin.126 mmDiameter of housing abutment
Camin.6 mmMinimum width of space required in housing on large side face
Cbmin.8 mmMinimum width of space required in housing on small side face
ramax.2 mmRadius of shaft fillet
rbmax.1.5 mmRadius of housing fillet
