09074/09194 Inch Tapered Roller Bearings

The 09074/09194 bearing set provides a reliable solution for high-load mechanical systems, featuring a separable cone and cup design. The precision-machined surfaces and hardened races ensure long-lasting performance under stress. Built for automotive applications like wheel hubs and transmissions, the bearing minimizes friction and handles torque effectively. With robust seals and DSBR’s stringent manufacturing standards, this bearing delivers consistent quality and ease of installation for both OEMs and aftermarket applications.

Contact Us download
Products
Technical Specification Technical Specification

Technical Specification of 09074/09194 Inch Tapered Roller Bearings







Specifications
Series9000
Cone Part Number9074
Cup Part Number9194
Design UnitInch
Cage MaterialStamped Steel
Dimensions
d - Bore

3/4 in

19.05 mm

D - Cup Outer Diameter

1.9380 in

49.225 mm

B - Cone Width

0.8480 in

21.539 mm

C - Cup Width

0.6875 in

17.463 mm

T - Bearing Width

0.9063 in

23.020 mm

Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1

0.06 in

1.5 mm

r - Cup Backface "To Clear" Radius2

0.140 in

3.56 mm

da - Cone Frontface Backing Diameter

0.94 in

24 mm

db - Cone Backface Backing Diameter

1.02 in

26 mm

Da - Cup Frontface Backing Diameter

1.79 in

44.50 mm

Db - Cup Backface Backing Diameter

1.54 in

39.12 mm

Ab - Cage-Cone Frontface Clearance

0.06 in

1.5 mm

Aa - Cage-Cone Backface Clearance

0.07 in

1.8 mm

a - Effective Center Location3

-0.36 in

-9.1 mm

Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)4

2500 lbf

11100 N

C1 - Dynamic Radial Rating (1 million revolutions)5

9630 lbf

42800 N

C0 - Static Radial Rating

9100 lbf

40500 N

Ca90- Dynamic Thrust Rating (90 million revolutions)6

1140 lbf

5050 N

Factors
K - Factor72.2
e - ISO Factor80.27
Y - ISO Factor92.26
Cg - Geometry Factor100.0452
